Made to measure in sizes you require

British woodworking federation approved

3 Generations of time-served master craftsmen

Denbigh Pedestrian Gate

The Denbigh pedestrian gate is the most economical of our pedestrian gates, but that is not to say say we skimp on quality or any other aspect of the gate!

Made to the same high standards as the rest of our gates whether you opt for the Softwood version or European Oak gate – it doesn’t matter to us, what matters is that we make you a gate to last!

Fancy a variation? As well as the close boarded version of the gate, an open boarded version is also available.

To obtain a price we need the height of gate required and gate width

Prices online are for sizes 700-2100mm in height & 600-1500mm width, for sizes outside these please contact us.

Want to use imperial instead of metric? Use our converter here

Enter your required gate height in mm, usually you will allow 50mm / 2" clearances under the gates.
Enter required gate width
Please select from our range of timbers
http://www.woodworkersuk.co.uk/wooden-gates/timber-gates-pedestrian/st-asaph-pedestrian-gates/?preview=true
Available sizes online for the Denbigh are 700mm to 2100mm high & 600mm to 1500mm wide. For sizes outside these please contact us at enquiries@woodworkersuk.co.uk for a personalised costing.
Diagram showing and explaining how to measure for single gates
Joggles are the protrusions on top corners of the gates, these give the mortice & tenon joints strength. As standard the joggles are arched/curved.
Open boarded or slatted gates are great if you live in a windy area, as they allow the wind to pass through the gates. Larger close boarded gates can be difficult, at times, to open into a strong wind; you run the risk of the wind dragging them out of your hands; with an open boarded gate, this can be greatly reduced.
As standard when looking at the rear of the gate you can see the horizontal rails & braces.
Looking at the rear of the gate, is the hinge side the left OR right hand side & do you intend to fit the hinges to front OR rear of the gate?
add a full thickness bottom rail
As standard gates have bottom rail that can only be seen from rear, from the front it is covered by the cladding. Add a full thickness bottom rails means the bottom rail can be seen from both sides of the gates, bottom rail being 5 3/4" / 145mm tall with the cladding being jointed into the rail.
Fixing stile options
Posts for fixing to a wall or other structure. Priced per stile. Supplied in same timber as your gates.
Posts for fixing to a wall or other structure. Priced per stile.( 95mm x 70mm with 20mm x 20mm loose stop) supplied in same timber as your gates.
4 way weather cut softwood posts
100mm x 100mm (+£54.00)
4 way weather cut softwood posts
125mm x 125mm (+£79.20)
4 way weather cut softwood posts
150mm x 150mm (+£112.80)
square tanalised softwood posts
175mm x 175mm (+£163.20)
square tanalised softwood posts
200mm x 200mm (+£187.20)
All priced per post. As a rule of thumb post size should be for every 12" (300mm) of gate, posts should be 1" (25mm) + 1" (25mm). Posts upto 150mm / 6" square are 4 way weather cut on top. Posts over this are square cut.
ironmongery options for pedestrian gates
All packs contain 1 Pair 14" Adjustable gate hinges, 1 No 6" Ringlatch plus all fixings & 1 8" Cabin hook. (* Black on galv & Marine grade stainless steel hinge options are 18" Adjustable hinges. Cabin hook for Stainless steel is a 4" Cabin hook).
All packs contain 1 1/2 Pair 14" Adjustable gate hinges, 1 No 6" Ringlatch plus all fixings & 1 8" Cabin hook. (* Black on galv & Marine grade stainless steel hinge options are 18" Adjustable hinges. Cabin hook for Stainless steel is a 4" Cabin hook).
All packs contain 1 Pair 18" Adjustable gate hinges, 1 No 6" Ringlatch plus all fixings & 1 8" Cabin hook. (*Cabin hook for Stainless steel is a 4" Cabin hook).
All packs contain 1 1/2 Pair 18" Adjustable gate hinges, 1 No 6" Ringlatch plus all fixings & 1 8" Cabin hook. (*Cabin hook for Stainless steel is a 4" Cabin hook).
gate locking options explained
Select your choice of locks if required. Mortice deadlocks are the most secure and operated by key from either side. Brenton Padbolts are lockable by way of a padlock (not supplied) and the Long throw locks fit to (usually the rear) of the gates, doube locking is key operated from either side, single locking is key operated from front, with latch on rear to unlock.
Any additional details you think might be relevant to help us build your bespoke product.
Grand total
Pay a deposit of 25% per item
Current lead times are approx 10-12 weeks at present

Description

Want a flat top pedestrian gate to fit an enclosed opening?

The Denbigh pedestrian gate can also be manufactured with a flat top to allow installation within an enclosed stone or brickwork opening.The Denbigh can be fitted within the opening the traditional way with two posts or we can manufacture a matching frame (without a cill) to match.

All we need to know is whether you require posts or a frame and be sure to let us know that it is being fitted within an enclosed opening so we can allow the required clearances for you. For prices on this please contact us @ enquiries@woodworkersuk.co.uk

Denbigh pedestrian gates – specifications

All top edges on any horizontal rails of the Denbigh gate feature an angled water run off, this stops the build up of moisture on your gates and makes for a longer lifespan.

The stiles of our Denbigh gate (vertical outer uprights of the gate frame) also have rounded outer edges.



Available in a choice of five timbers –

Unsorted Scandinavian Redwood (Softwood)
Accoya (Modified Acetylated Softwood)
Meranti (Hardwood)
Idigbo (Hardwood)
Prime European Oak (Hardwood) Wedged morticed and tenon jointed construction

Height – Made to measure
Width – Made to measure
Heads/top rails & stiles – 2 3/4″ x 2 3/4″ / 70mm x 70mm
Hidden rails – (Visible from rear only) 2 3/4″ x 1 7/8″ / 70mm x 48mm
Boarding – 3 3/4″ x 5/8″/ 95mm x 15mm



Our Guarantee

Gate Expectation’s mission is to bring the highest quality bespoke measured wooden gates, side hung wooden garage doors and general joinery items to the market at a quality and price point that can’t be matched.

If not completely satisfied we offer 30-day no hassle returns on all our off-the-shelf range.

Three generations of master carpentry and joinery experience in each and every product. Read more about our history here.

Every thing we manufacture is made to measure by our British Woodworking Federation Approved  Joiners.

Upon receipt of any order then an full order confirmation is sent out (this will follow the auto  generated email that you receive immediately after placing an order).

This order confirmation email gives you a chance to double check sizes and for us to confirm final  details.

Once an order is received you will receive a ‘completion week’ within your order confirmation  email. Once the gate is ready for despatch we will contact you to arrange a suitable day for delivery, we do not just send the completed gates out and hope for the best!

Deliveries are Tuesdays-Fridays only, excluding any Bank Holidays/Public Holidays.

Where possible we try and use a dedicated van for deliveries so like to try and group several  deliveries within the same area on the same day, but we do also use Nationwide carriers as well.

For deliveries further afield we will ship on a carrier.

All prices gate prices include delivery to most parts of the UK mainland. Exclusions to this are  highlands or Scotland and off shore areas of the UK (Scottish Islands, Isle of Wight, Isle of Man,  Channel Islands).

Additional delivery charges

Scottish Highlands (3-5 day) £46

Scilly / Scottish Islands (3-5day) £56

Isle of Wight £36

Isle of Man (3-5 day) £76

Channel Islands (3-5 day) £56

All inc VAT

Please note that due to Brexit we are currently not shipping to Northern Ireland or Europe.
